5 pcs. Magnetic Flux Indicator Type I (Castrol strips type (G)eneral)

€ 142

(excl. VAT)

Model/Product no.: #F000410
  • Quality
  • Great prices
  • Personal customer care

5 pcs. of flux indicator strips - Type I (Type G) with brass finish.


Magnetic Flux Indicator strips are widely used to indicate the presence of induced magnetic fields during the magnetic particle inspection method of ferromagnetic materials. Flux indicators give evidence of an external field in the air above the magnetized surface, and in some circumstances, can be used to obtain a semi-qualitative estimate of the tangential field strength H.

Type I indicators are typically used for general engineering applications and Type II Indicators are used for aerospace applications. Both types consist of three laminations measuring 50 X 12 mm which are fixed together to form a sandwich structure which is nominally 0.15 mm thick. The outer lamination has 3 interruptions which are parallel to the long side. The width of these interruptions and the material of the outer lamination mean’s that Type I indicators respond to a weaker field than Type II strips. Both types are protected by a polymeric layer and can be differentiated by the Roman numeral next to the logo. Flux indicators have the advantage of being flexible enough so that they can be bent to fit the contours of a work piece, but robust enough to enable them to be used many times. They may also be cut into smaller pieces to allow them to be fixed in recesses and otherwise inaccessible locations on the work piece.
